Physical Properties

Metric

English

Comments

Density

1.14 g/cc

0.0412 lb/in³

DAM; ISO 1183

Mechanical Properties

Metric

English

Comments

Tensile Strength, Yield

55.0 MPa
@Temperature 23.0 °C

7980 psi
@Temperature 73.4 °F

50%RH; ISO 527

85.0 MPa
@Temperature 23.0 °C

12300 psi
@Temperature 73.4 °F

DAM; ISO 527

Elongation at Break

20.0 %
@Temperature 23.0 °C

20.0 %
@Temperature 73.4 °F

DAM; ISO 527

40.0 %
@Temperature 23.0 °C

40.0 %
@Temperature 73.4 °F

DAM, 50mm/min; ISO 527

>= 50.0 %
@Temperature 23.0 °C

>= 50.0 %
@Temperature 73.4 °F

50%RH; ISO 527

Elongation at Yield

4.00 %
@Temperature 23.0 °C

4.00 %
@Temperature 73.4 °F

DAM; ISO 527

25.0 %
@Temperature 23.0 °C

25.0 %
@Temperature 73.4 °F

50%RH; ISO 527

Tensile Modulus

1.40 GPa
@Temperature 23.0 °C

203 ksi
@Temperature 73.4 °F

50%RH; ISO 527

3.10 GPa
@Temperature 23.0 °C

450 ksi
@Temperature 73.4 °F

DAM; ISO 527

Flexural Modulus

2.80 GPa
@Temperature 23.0 °C

406 ksi
@Temperature 73.4 °F

DAM; ISO 178

Charpy Impact, Notched

0.550 J/cm²
@Temperature 23.0 °C

2.62 ft-lb/in²
@Temperature 73.4 °F

DAM; ISO 179/1eA

Izod Impact, Notched (ISO)

5.00 kJ/m²
@Temperature -40.0 °C

2.38 ft-lb/in²
@Temperature -40.0 °F

DAM; ISO 180/1A

5.00 kJ/m²
@Temperature 23.0 °C

2.38 ft-lb/in²
@Temperature 73.4 °F

DAM; ISO 180/1A

Electrical Properties

Metric

English

Comments

Comparative Tracking Index

>= 600 V
@Temperature 23.0 °C

>= 600 V
@Temperature 73.4 °F

DAM; UL 746A

600 V
@Temperature 23.0 °C

600 V
@Temperature 73.4 °F

DAM; UL 746A

Thermal Properties

Metric

English

Comments

Melting Point

262 °C

504 °F

DAM, 10°C/min; ISO 11357-1/-3

Deflection Temperature at 0.46 MPa (66 psi)

200 °C

392 °F

DAM; ISO 75-1/-2

Deflection Temperature at 1.8 MPa (264 psi)

70.0 °C

158 °F

DAM; ISO 75-1/-2

UL RTI, Electrical

140 °C
@Thickness 0.710 mm

284 °F
@Thickness 0.0280 in

DAM; UL 746B

140 °C
@Thickness 1.50 mm

284 °F
@Thickness 0.0591 in

DAM; UL 746B

140 °C
@Thickness 3.00 mm

284 °F
@Thickness 0.118 in

DAM; UL 746B

UL RTI, Mechanical with Impact

95.0 °C
@Thickness 0.710 mm

203 °F
@Thickness 0.0280 in

DAM; UL 746B

110 °C
@Thickness 3.00 mm

230 °F
@Thickness 0.118 in

DAM; UL 746B

110 °C
@Thickness 1.50 mm

230 °F
@Thickness 0.0591 in

DAM; UL 746B

UL RTI, Mechanical without Impact

115 °C
@Thickness 0.710 mm

239 °F
@Thickness 0.0280 in

DAM; UL 746B

125 °C
@Thickness 1.50 mm

257 °F
@Thickness 0.0591 in

DAM; UL 746B

125 °C
@Thickness 3.00 mm

257 °F
@Thickness 0.118 in

DAM; UL 746B

Flammability, UL94

V-2
@Thickness 1.50 mm

V-2
@Thickness 0.0591 in

DAM; UL94

V-2
@Thickness 3.00 mm

V-2
@Thickness 0.118 in

DAM; UL94

V-2
@Thickness 0.710 mm

V-2
@Thickness 0.0280 in

DAM; UL94

V-2
@Thickness 1.50 mm

V-2
@Thickness 0.0591 in

DAM; IEC 60695-11-10

V-2
@Thickness 3.00 mm

V-2
@Thickness 0.118 in

DAM; IEC 60695-11-10

V-2
@Thickness 0.710 mm

V-2
@Thickness 0.0280 in

DAM; IEC 60695-11-10

Glow Wire Test

725 °C
@Thickness 1.50 mm

1340 °F
@Thickness 0.0591 in

Ignition Temp; DAM; IEC 60695-2-13

725 °C
@Thickness 3.00 mm

1340 °F
@Thickness 0.118 in

Ignition Temp; DAM; IEC 60695-2-13

725 °C
@Thickness 0.710 mm

1340 °F
@Thickness 0.0280 in

Ignition Temp; DAM; IEC 60695-2-13

850 °C
@Thickness 0.710 mm

1560 °F
@Thickness 0.0280 in

Flammability Index; DAM; IEC 60695-2-12

960 °C
@Thickness 1.50 mm

1760 °F
@Thickness 0.0591 in

Flammability Index; DAM; IEC 60695-2-12

960 °C
@Thickness 3.00 mm

1760 °F
@Thickness 0.118 in

Flammability Index; DAM; IEC 60695-2-12

Processing Properties

Metric

English

Comments

Melt Temperature

280 - 300 °C

536 - 572 °F

DAM

290 °C

554 °F

DAM

Mold Temperature

50.0 - 90.0 °C

122 - 194 °F

DAM

70.0 °C

158 °F

DAM

Drying Temperature

80.0 °C

176 °F

DAM

Dry Time

2 - 4 hour

DAM

Moisture Content

<= 0.200 %

DAM
