Physical Properties
Metric
English
Comments
| Specific Gravity |
1.20g/cc |
1.20g/cc |
| Water Absorption |
1.50 %
@Time 86400 sec |
1.50 %
@Time 24.0 hour |
| Linear Mold Shrinkage |
0.00200-0.00600cm/cm |
0.00200-0.00600in/in |
| |
Mechanical Properties
Metric
English
Comments
| Hardness, Rockwell R |
81.0 |
81.0 |
| Tensile Strength at Break |
34.5MPa |
5000psi |
| Tensile Strength, Yield |
33.3MPa |
4830psi |
| Elongation at Break |
45.0 % |
45.0 % |
| Flexural Modulus |
1.52GPa |
220ksi |
| Flexural Strength |
43.7MPa |
6340psi |
| Izod Impact, Notched |
1.03J/cm
@Temperature -40.0 °C |
1.93ft-lb/in
@Temperature -40.0 °F |
| |
3.53J/cm
@Temperature 23.0 °C |
6.61ft-lb/in
@Temperature 73.4 °F |
| |
Electrical Properties
Metric
English
Comments
| Volume Resistivity |
1.00e+13-1.00e+15ohm-cm |
1.00e+13-1.00e+15ohm-cm |
| Dielectric Constant |
3.30 - 3.80
@Frequency 1.00e+6 Hz |
3.30 - 3.80
@Frequency 1.00e+6 Hz |
| Dissipation Factor |
0.0100 - 0.150
@Frequency 1.00e+6 Hz |
0.0100 - 0.150
@Frequency 1.00e+6 Hz |
| |
Thermal Properties
Metric
English
Comments
| CTE, linear |
110-170µm/m-°C |
61.1-94.4µin/in-°F |
| Specific Heat Capacity |
1.26-1.67J/g-°C |
0.301-0.399BTU/lb-°F |
| Thermal Conductivity |
0.170-0.330W/m-K |
1.18-2.29BTU-in/hr-ft²-°F |
| Deflection Temperature at 0.46 MPa (66 psi) |
85.0°C |
185°F |
| Deflection Temperature at 1.8 MPa (264 psi) |
76.0°C |
169°F |
| Vicat Softening Point |
98.0°C |
208°F |
| |
